Year: 2008
Manufacturer: Newmar
Model: Essex
RV Type: Class A
Condition: New
  • Two 15M Penguin™ Heat Pump Central Air Conditioners with Remote Control Thermostat (41 ft. Floorplans)
  • Three 15M Penguin™ Heat Pump Central Air Conditioners with Remote Control Thermostat (45 ft. Floorplans)
  • Hydronic Zone Heating System
  • Dash Heater and High-Output Air Conditioner
  • Propane Leak Detector
  • 30 inch Convection Microwave Oven
  • Two-Burner Recessed Cooktop
  • Polished Corian® Range Cover
  • Norcold® 17 Cu.Ft. Four-Door Refrigerator with Auto Defrost and Water Dispenser
  • One-Piece Washer/Dryer Prep
  • Sony® LCD TV in Living Area
  • Pioneer® AM/FM/XM with CD, MP3 Adapter, Navigation System and Color Rearview Monitor System
  • Surround Sound System with CD and DVD Player
  • Bose Wave® Radio with CD Player and Alarm Clock in Bedroom
  • TV Antenna with Power Lift, One Exterior Jack and Two Interior Jacks
  • Satellite Prep—Phone, TV Jack and Receptacle
  • Telephone Connection with Phone Jacks in Living and Dash Areas
  • 8.5 inch x 11 inch Safe
  • Air Horns
  • Universal Remote Control
  • Audio/Video Smart-Source Switch with Remote Control
  • 10 Bc Fire Extinguisher, and Carbon Monoxide and Smoke Detectors
  • High Definition Component Wiring and HD-ready Video Switching System
  • Trip Tek™ Electronic Travel Information (Displayed on Rearview Monitor)
  • 32 inch Sony® LCD TV in Bedroom
  • TV Antenna Is Up Warning Signal
  • Cable TV Connection with Rg6 Coax
  • Sideview Cameras with Image Displayed on Rearview Monitor Screen
  • Northern Maple Hardwood Unitized Cabinets with Fully Overlayed Raised-Panel, Double-Cathedral Cabinet Doors
  • Hidden-Leaf Dinette Table with Corian® Top and Four Chairs (Two Fixed and Two Folding)
  • Polished Corian® Countertop in Kitchen with Undermounted Solid Surface Sink and Flush Sink Covers
  • Polished Corian® Countertop with Integrated Bowl in Bathroom
  • Polished Corian® Countertop on Bedroom Nightstands
  • Adjustable Pullout Pantry Shelves
  • Residential Style Full Extension Ball Bearing Drawer Guides
  • Drawers with Dove-Tailed Sides and Maple Bottoms
  • Concealed Hinges on Cabinet Doors
  • Villa™ Furniture
  • Ultraleather/Vinyl Heated Driver Seat with Eight-Way Power, Power Lumbar and Power Recline
  • Ultraleather/Vinyl Heated Oversized Passenger Seat with Eight-Way Power, Power Lumbar, Power Recline and Power Footrest
  • Lifts on Bed Top to Access Storage Area
  • Cedar Paneling in Rear Wardrobe
  • Storage Shelves Recessed into Rear Cap of Rear Wardrobe Floorplans
  • King Koil™ Turn-Free Radius Cornered Mattress with Quilted Bedspread, Matching Bedskirt, Accent Pillows and Faux Fur Throw
  • King Bed with Hardwood, Raised-Panel Bed Base
  • Carpeted Wardrobe Bottoms with Pearl Cream Headliner on Shelves and Overhead Cabinet
  • 12.5 kW Cummins Onan® Diesel Quiet Generator on Hydraulic Slide and Auto Changeover
  • 50-Amp Electrical Service with Flexible Cord on Power Cord Rewind Reel
  • Four 6-Volt House Batteries on Pullout Tray
  • Battery Disconnect Switch
  • 110-Volt Exterior Receptacle
  • 5-Watt Solar Panel
  • 2800-Watt Pure Sine-Wave Inverter with Automatic Generator Start
  • Emergency Start Switch
  • Exterior TV Jack
  • Midship Side Turn Signals
  • Recessed Docking Lights
  • Switched Receptacle for Engine Block Heater
  • Recessed Halogen Lights in Ceiling and Overhead Cabinets
  • Lighted Wardrobes with Automatic Switches
  • Slideout Information Voice Module
  • Manually Operated Hold-to-Run Slideout Switch
  • ICC Light Switch
  • Two 12-Volt Auxiliary Receptacles on Dashboard
  • Interior Courtesy Lights
  • Mood Lights Recessed in Lambrequins, Kitchen Valance and Bed Base
  • Daylight Headlight System
  • Multi-Plex Electrical System
  • Exterior Security Lights on Each Side
  • Full-Paint Masterpiece Finish™ with Super Clear Coat and Diamond Shield Front Protective Film
  • One-Piece Bonded Windshield
  • Convex Exterior Chrome Mirrors with Remote Control, Defrost and Turn Signal Indicators
  • Entrance Door with Automatic Double Step
  • Dual Latch Front Door with Power Flush Stepwell Cover
  • Lighted Exterior Storage Compartments with Cargo Liner Controlled by Interior Master Switch
  • Pantographic Basement Doors with Side-Hinged Doors Under Slideouts
  • Power Locking Baggage Doors
  • 15,000 lb. Towing Hitch with Two Extra 14-Gauge Wires
  • Lighted Acrylic Assist Handle at Entrance Door
  • Rear Protective Tow Guard with Stainless Steel Newmar Name Cutout
  • Holding Tank Levels Displayed in Exterior Water Works Compartment
  • Squeegee in Exterior Compartment
  • Undercoating
  • Mud Flaps
  • Sculpted Padded Vinyl Ceiling
  • Power Vertical Drop-down Windshield Privacy Shade
  • Lined Day/Night Pleated Window Shades and Lambrequins
  • Hardwood Ornate Fascia on Living Area Slideout
  • Polished Porcelain Floor Tile in Kitchen, Bathroom and Entrance Areas
  • Interior Assist Handle at Main Entrance Door
  • Power Driver- and Passenger-Side Sun Shades
  • Power-Activated Sun Visors
  • Polished Corian® Window Sills
  • Deluxe Carpeting with High-Density Padding and Sculptured Carpet in Living and Bedroom Areas
  • Raised-Panel Interior Passage Doors
  • Plumbing & Bath
  • Demand Water System with Aquajet™ ES Pump
  • Sewage Holding-Tank Rinse
  • Thetford™ Aria Sculptured China Stool (Thetford™ Vacuum Flush Stool in Rear Baths)
  • Towel Bar, Tissue Holder, Towel Ring and Robe Hook
  • Exterior Convenience Wash Station—Hot/Cold Water, Soap and Towel Dispenser
  • Fiberglass Tub/Shower and Glass Shower Door
  • Two Monitor Panels (One Interior and One in Exterior Water Compartment)
  • MANABLOC® Plumbing System
  • Monoplex Water-Pump Switches Located in Bathroom, Kitchen and Near Gate Valves
  • Auto Water-Fill System
  • Designer Faucets in Bathroom and Kitchen
  • Whole House Water Filter
  • Water Filter with Drink Dispenser at Kitchen Sink
  • Automatic Rewind Water-Hose Reel
Floorplans 2008 EXDP 4103 2008 EXDP 4502 2008 EXDP 4508 2008 EXDP 4510 2008 EXDP 4514 2008 EXDP 4515
App. Overall Length 40' 11" 44' 11" 44' 11" 44' 11" 44' 11" 44' 11"
Width 101.5" 101.5" 101.5" 101.5" 101.5" 101.5"
App. Overall Height 12' 10" 12' 10" 12' 10" 12' 10" 12' 10" 12' 10"
Interior Width 95.5" 95.5" 95.5" 95.5" 95.5" 95.5"
Interior Height 84" 84" 84" 84" 84" 84"
Grey 65 gal. 65 gal. 65 gal. 65 gal. 65 gal. 65 gal.
Sewage 45 gal. 45 gal. 45 gal. 45 gal. 45 gal. 45 gal.
Water 105 gal. 105 gal. 105 gal. 105 gal. 105 gal. 105 gal.
LP 32 gal. 32 gal. 32 gal. 32 gal. 32 gal. 32 gal.
Furnace 50,000 Btu 50,000 Btu 50,000 Btu 50,000 Btu 50,000 Btu 50,000 Btu
