Year: 2007
Manufacturer: Komfort
Model: Trailblazer
RV Type: Travel Trailer
Condition: New
Features
TRAILBLAZER STANDARD FEATURES
  • Full 2-Year Transferable warranty.
  • Gel coat fiberglass exterior
  • Molded fiberglass front cap
  • Diamond plant rear bumper & front protection.
  • Welded aluminum sidewall structure 16”-OC
  • 8’3” Wide Body Design (3-didget models)
  • Polyethylene 1-pc. Roto molded holding tanks & wheel wells.
  • Rack & pinion 12-V electric slide system with manual over ride.
  • 15” radial tires & mud flaps.
  • Heavy duty stab jacks (welded).
  • Spare tire hidden under chassis.
  • Awning
  • Exterior light group.
  • Gutter w/downspouts on both side of the trailer.
  • Radius entry & baggage doors.
  • Deluxe 12Vstereo system.
  • TV antenna with booster.
  • Exterior shower.
  • Bedroom roof vent
  • Power vent in bath
  • Dual pane skylight in bath.
  • Pre-plumbed for outside RVQ.
  • 6 Cu. Ft. double door refrigerator.
  • Large 22” range / oven.
  • Deep – double bowl kitchen sinks.
  • Extra large lavvy bowls.
Model T211S T23S T240S T25BS T254S T263S T275S T276S T285S T291BS
Length 23'5" 25'11" 26'6" 26'9" 27'11" 29'9" 29'2" 29'7" 32'3" 33'11"
Width 8'3" 8'0" 8'3" 8'0" 8'3" 8'3" 8'3" 8'3" 8'3" 8'3"
Height without A/C 9'5" 9'5" 9'5" 10'1" 10'1" 10'1" 10'1" 10'1" 10'1" 10'1"
Interior Height 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6" 6'6"
Bedroom Height (for FW) NA NA NA NA NA NA NA NA NA NA
GAWR - lbs. 7,000 7,000 7,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000
GVWR - lbs. 7,635 7,615 7,635 10,000 10,000 10,000 10,000 10,000 10,000 10,000
Unloaded Weight - lbs. 5,205 5,525 5,845 6,525 6,785 6,700 7,095 6,995 7,815 7,775
Cargo Capacity - lbs. 1,902 1,562 1,262 2,947 2,687 2,772 2,377 2,477 1,657 1,697
Hitch Weight - lbs. 360 615 635 855 775 760 1,175 715 1,295 1,115
Fresh WaterTank - Gal. 56 * 56 * 56 * 56 * 56 * 56 * 56* 56 * 56 * 56*
Grey Water Tank - Gal. 40 40 40 40 * 40 * 40 * 40 * 40* 40* 40 *
Black Water Tank - Gal. 40 40 40 40* 40* 40* 40* 40* 40* 40*
Furnace (BTU) 25M 25M 25M 25M 25M 25M 25M 25M 25M 25M
Awning Size - ft. 13' 16' 16' 16' 16' 16' 16' 16' 21' 19'
Floorplans (Click to enlarge)
