2004 Fleetwood TERRY DAKOTA Specs, Towing Weight, Floorplan + Features
Photo Tour
Available Photos (Click to enlarge)
|
Free Price Quote - No Obligation to Buy
|
| Year: | 2004 |
|---|---|
| Manufacturer: | Fleetwood |
| Model: | TERRY DAKOTA |
| RV Type: | Travel Trailer |
| Condition: | Used |
| Price Range: | $15,000 - $23,000 |
Description
Terry Dakota puts quality, functionality and affordability together to get you on the road. Lightweight construction allows this product to be towed behind most of today's SUV's. Dakota is built with attention to detail and provides ample storage and accommodations. This RV is all about value.
Features
EXTERIOR
- Smooth Fiberglass Siding
- Aluminum Framed Sidewalls
- Rear Bumper w/Sewer Hose Carrier and Aluminum Cover
- Locking, Insulated Luggage Doors
- One-Piece Seamless Roof
- Molded Wheel Well Skirts
- Radius Truss Roof Rafters
- Hitch Light
- Entry Step Light
- Patio Light-Interior Switch
- Security Light (Doorside)
- Sub-Floor Fresh Water Holding Tank
- Welded, Dual Battery Rack (Travel Trailer Models Only)
- Tinted Safety Glass Windows
INTERIOR
- Overhead Storage Cabinets
- Innerspring Mattress (Most Models)
- Decor Wall Border
- Decor-Coordinated Bedspread (Most Models)
- Miniblinds Throughout (Except Bunk Windows)
- Bedroom Headboards
- Pantry with Pull-Out Basket (Most Models)
- Raised Panel Overhead Cabinet Doors
- Pedestal Table with Large Dinette Window
| 255BHS | 24BH | 28BH | 830Y | |
| GVWR (Gross Vehicle Weig... | 8,100 | 6,200 | 7,500 | 7,500 |
| Gross Dry Weight (lbs.)2... | 5,952 | 4,190 | 4,574 | 5,472 |
| Maximum Carrying Capacit... | 2,148 | 2,040 | 2,926 | 2,028 |
| Hitch Dry Weight (lbs.)2... | 1,128 | 494 | 562 | 637 |
| Length (' and ")4,6... | 27' 6" | 26' 6" | 29' 7" | 30' 11" |
| Height (' and ")5,6 | 10' 9" | 9' 1" | 9' 11" | 9' 11" |
| Tire Size (Load Range) | ST205/75R 15"(C) | ST205/75R 14"(C) | ST205/75R 15"(C) | ST205/75R 15"(C) |
| Fresh Water Holding Tank... | 40 | 40 | 40 | 40 |
| Gray Water Holding Tank ... | 40 | 40 | 40 | 40 |
| Black Water Holding Tank... | 40 | 40 | 40 | 40 |
| LP Gas Capacity (lbs.)6 | 60 | 60 | 60 | 60 |
1. (Gross Vehicle Weight Rating) is the maximum permissible weight of this trailer when fully loaded. It includes all weight at the trailer axle(s) and tongue or pin.
2. All dry weights are based on the standard model and do not include optional features or equipment.
3. Maximum Carrying Capacity is determined by subtracting Gross Dry Weight from GVWR. Maximum Carrying Capacity includes all fluids, optional features, equipment, and personal cargo.
4. Trailer length includes 3' 6" for hitch; fifth wheel includes standard pin box.
5. Add 9" if equipped with optional roof air conditioner.
6. Approximate.
7. Add 10" if equipped with optional spare tire and carrier.
