2005 Damon Corporation DAYBREAK Specs


Year: 2005
Manufacturer: Damon Corporation
Model: DAYBREAK
RV Type: Class A
Condition: New
Price Range: $61,000 - $93,000
  2960 LE 2965 3060 3270 3272 3295
Chassis Workhorse® / Ford® Workhorse® / Ford® Workhorse® / Ford® Workhorse® / Ford® Workhorse® / Ford® Workhorse® / Ford®
Wheelbase 178 190 190 216.5 208 208
Overall length 31' 2" 29' 10" 31' 8" 34' 9" 33' 9" 32' 9"
Overall width 101" 101" 101" 101" 101" 101"
Overall height with AC 11' 8" 11' 8" 11' 8" 11' 8" 11' 8" 11' 8"
Std. weight (appx. lbs.) 11,947 / 12,551 13,160 / 13,810 N/A 14,074 / 14,609 N/A N/A / 14,525
GVWR 15K / 15.7K 17K / 20.5K 15K / 15.7K 18K / 20.5K 18K / 20.5K 18K / 20.5K
GCWR 21K 21K / 26K 21K 21K / 26K 21K / 26K 21K / 26K
Fresh water (appx. gal.) 75 75 75 75 75 75
Grey / black water (appx... 50 50 50 50 50 50
LP (lbs.) 103.5 103.5 103.5 103.5 103.5 103.5
Sleeping capacity 4 4 4 5 5 4
Exterior storage capacit... 78 46 78 52 72 78
Interior drawers 9 9 10 11 15 15
Interior storage capacit... 6 6 7 9 8 7
Fuel capacity (appx. gal... 75 75 75 75 75 75
Floorplans (Click to enlarge)
2960LE
2965
3060
3270
3272
3295
