2008 Forest River All American Sport Specs, Towing Weight, Floorplan + Features
Photo Tour
Available Photos (Click to enlarge)
|
Free Price Quote - No Obligation to Buy
|
| Year: | 2008 |
|---|---|
| Manufacturer: | Forest River |
| Model: | All American Sport |
| RV Type: | Fifth Wheel |
| Condition: | New |
Description
If your idea of camping involves more than sitting around the campfire, then the new "XLR" Toy Hauler" by Forest River fulfills your definition of outdoor fun. This line of fun-packed travel trailers and fifth wheels includes an 8' x 12' cargo area and loading ramp for hauling ATV's, dirt bikes, snowmobiles, bicycles, or other outdoor toys. The living quarters include all the popular features and furnishings of a comfortable, fully appointed RV. Even slide-outs are available on selected models. Designed for active lifestyles, the new "XLR"adds more adventure to your family camping.
Features
EXTERIOR
- 102" Width
- 30" Radius Front Entry Door
- Triple Entry Step on Fifth Wheels
- Double Entry Step on Travel Trailers
- 26" Radius Secondary Door w/ Double Step
- 15 - 20ft. Awnings (w/a)
- Large Tinted Jalousie Clamp Ring Windows, Radius Cornered w/ Screens and Vented Side Windows in Main Slide-Out
- Enclosed Gooseneck (Fifth Wheels Only)
- Hitch Light
- (2) 30# LP Tank w/ Auto Change Over
- LP Tank Cover (Travel Trailer)
- Stabilizer Jacks
- Power Front Jacks on Fifth Wheels
- Fiberglass Front Cap
- Large Pass Through Basement Storage
- Outside Shower
- Spare Tire, Wheel and Carrier Mount
- Graphics (Choice option)
- Trail Air Pin Box
- Slide Selector Switches
INTERIOR
- Four (4) Color Coordinated Interiors
- 6 Panel Wood Grain Passage Doors
- Full 44" Booth Dinette w/ Easy Entry
- Double Pedestal Table
- Bedroom and Kitchen Roof Vent
- Night Shades
- Color Coordinated Drapes & Valances
- Queen Bed-Finished Bed Base w/ Gas Lifts
- Predrilled and Counter Sunk Fastened Cabinetry with Lumber-Core Cabinet Styles
- Plush Carpet with Padding
- TV Shelf and Outlet in Bedroom
- Coordinating Wallpaper Border
- Etched Overhead Cabinet Doors in Slide-Out
- Metal Drawer Guides Located on Both Sides of All Drawers
- Strategically Placed Antique Brass Hardware
- Hide-A-Bed w/ 2 Throw Pillows - Fifth Wheels
- Bedspreads with Matching Pillows and Shams
- Headboard
- Mattress Upgrade
- Interior Lighting Package
- Range Cover
- Raised Refer Door Insert
- Oak Facing Around Main Slide-Out
- Shower Stall Glass Door - Fifth Wheel
- Skylight Over Shower
- Pots and Pans Drawer Under Dinette
- Laminated Counter Tops w/ Matching Radius Edges
- Residential 60/40 Sink with 2 Sink Covers
APPLIANCE/EQUIPMENT
- DVD/CD/MP3/AM/FM/Weather Band High Power Digital Surround Sound
- 19" LCD Flat Screen Television Hooked up Through Surround Sound System - Fifth Wheel (27" TV in 385RLTS)
- 6 Gal Gas/Electric DSI Water Heater
- Three-Burner Range/w 22" Oven
- Microwave w/ Carousel
- 35,000 BTU Furnace (Floor Ducted)
- 13,500 BTU Ducted Central Air w/ "Quick Cool" Feature
- Power Range Hood w/ Light
- TV Hook-Up
- Satellite Prep
- Cable Hook Up
- Water Heater By-Pass
- "Full Coach" 100% Water Filtering System
- 6 Cubic Foot Double Door Refrigerator
- Two Fantastic 12" Fans w/ 10 Blades (Cargo and Toilet Area)
CONSTRUCTION
- Checker Board Steel Construction in Cargo Area
- Double Welded Aluminum-Framed Sidewalls
- Vacuum Bonded Laminated Sidewalls
- Powder Coated Frame w/ Mig Welded Outriggers
- Enclosed Underbelly
- Vacuum Banded Laminated Bath Deck
- Vacuum Bonded Laminated Front Wall
- 5/8" Plywood Tongue & Groove Decking (Living Area)
- 5" Truss Roof Rafters
- 3/8" Roof Decking (Entire Roof)
- 1 Piece 2 Ply Tuff Ply Rubber Roof Membrane w/ built in Fire Retardant
- Awning Drip Rail w/ Down Spouts
- 2" x 3" Floor Joists 12" On Center
- R-9 Insulation
- Hydraulic Rack and Pinion Slide-Outs w/ Manual Expansion and Contraction Capabilities
- 6 ft. 4 in. Interior Slide-Out Height
AXLE/FRAME
- Al-Ko Rubber Independent Suspension
- Axle System w/ Ultra Lube
- (2) 5200# on Travel Trailer
- (2) 7000# on 36CKS
- (3) 5200# on 375 and 385's
- All Wheel Electric Brakes
- Morton Silver Clear Coat Wheels w/ Stainless Steel Center Hub
- 8" Box Tube Frame on Travel Trailer
- 10" I-Beam Construction - 12" on 385CKTS (Fifth Wheels)
- Low Ramp
SECURITY & SAFETY
- Flush Door Latch w/ Dead Bolt Locks
- Smoke, Gas, and CO Detector
- LP Leak Detector
- Fire Extinguisher
- GFI Receptacle in Kitchen, Bath and Outside
- Screen Doors w/ Safety Latch
- Scare Light
- Porch Lights
- Front Step Light
- LED Clearance Lights
- Break Away Switch
CARGO AREA
- 102" Exterior Width
- 98" Interior Width
- Spray on Liner
- Fiberglass Sidewalls
- (2) 110 Volt Outlets
- 24" Diamond Plate Sidewall Base
- 7 ft. 0 in. Ramp Door
- Checker Board Steel Supports Side to Side and Front to Rear
- Fantastic Fan w/ Wall Switch
- Large Tinted Window w/ Screen
- Vapor Barrier Wall
- Wood Cabinets w/ Shelf and Netting - Fifth Wheels
- Ventilation Doors
- Directional Loading Lights
- TV Outlet
- Rear Entrance Door w/ Screen Door
XLR SERIES INTERIOR FEATURES
- Rockford Fosgate Sound System with Amp & Subwoofer
- MP3/Ipod Ready
- AM/FM/CD Player
- 24" TV and DVD Player
- Satellite/Cable TV Ready
- TV Antenna with Power Booster
- XLR Control Panel
- Solid Wood Cabinet Doors
- Solid Wood Slide Out Fascia
- Solid Oak Raised Refrigerator Panels
- Large 8 Cu. Ft. Refrigerator
- Microwave
- 22" Oven with 3 Burner Range
- Residential Single Lever Faucet with Pull Out Sprayer
- Residential Ceiling Fan
- Decorative Light Package
- Hide-A-Bed Sofa
- Lambrequins Valances & Night Shades
- Queen Bed Loft Over Cargo Area
- Skylight Over Shower
- Porcelain Foot Flush Toilet
XLR SERIES EXTERIOR FEATURES
- 102" Wide-Body
- Gel Coat Fiberglass
- Gel Coat Front Cap
- External Speakers
- Generator Prep with Transfer Switch
- LED Clearance Lights
- Detachable Exterior Ladder
- Triple Ultra Lube Axles
- Aluminum Wheels with Radial Tires
- 12 Volt Electric Front Landing Gear
- 12 Volt Battery Disconnect
- Prepped For Two Batteries
- Black Tank Flush
- Full System Water Filtration
| 37X12 | 38X12 | 39X12 | |
| Hitch Weight | 2,720 lbs. | 2,990 lbs. | 2,844 lbs. |
| Ship Weight | 12,330 lbs. | 12,725 lbs. | 13,645 lbs. |
| GVWR | 17,000 lbs. | 17,000 lbs. | 18,000 lbs. |
| Length | 38 ft. 10 in. | 38 ft. 10 in. | 41 ft. 8 in. |
| Fresh Water | 100 Gal. | 100 Gal. | 100 Gal. |
| Grey Water | 77 Gal. | 77 Gal. | 87 Gal. |
| Black Water | 50 Gal. | 50 Gal. | 54 Gal. |
| Cargo Size | 12 ft. | 12 ft. | 12 ft. |
| Tire Sizes | 235/75/R15D | 235/75/R15D | 225/75R 15D |
| 365CKSS | 375CKDS | 385CKTS | 385RLTS | |
| Ship Weight | 12,570 lbs. (5702 kg) | 13,470 lbs. (6110 kg) | 13,930 lbs. (6318 kg) | 13,940 lbs. (6323 kg) |
| GVWR | 16,590 lbs. (7525 kg) | 18,360 lbs. (8328 kg) | 18,590 lbs. (8432 kg) | 18,420 lbs. (8355 kg) |
| Living Area Cargo ... | TBA | TBA | TBA | TBA |
| Total Cargo Capaci... | TBA | TBA | TBA | TBA |
| Hitch Weight | 2,590 lbs. (1175 kg) | 2,760 lbs. (1252 kg) | 3,160 lbs. (1433 kg) | 2,720 lbs. (1234 kg) |
| Axle Weight | 9,980 lbs. (4527 kg) | 10,710 lbs. (4858 kg) | 10,770 lbs. (4885 kg) | 11,220 lbs. (5089 kg) |
| Exterior Height | 13 ft. 5 in. (4.09 m) | 13 ft. 5 in. (4.09 m) | 13 ft. 5 in. (4.09 m) | 13 ft. 5 in. (4.09 m) |
| Exterior Length | 37 ft. 2 in. (11.33m) | 40 ft. 3 in. (12.27m) | 41 ft. 2 in. (12.55 m) | 40 ft. 10 in. (12.45m) |
| Fresh Water | 90 gal. (340 L) | 90 gal. (340 L) | 90 gal. (340 L) | 90 gal. (340 L) |
| Gray Water | 77 gal. (291 L) | 77 gal. (291 L) | 77 gal. (291 L) | 77 gal. (291 L) |
| Waste Water | 50 gal. (189 L) | 50 gal. (189 L) | 50 gal. (189 L) | 50 gal. (189 L) |
| Water Heater | 6 gal. (22 L) | 6 gal. (22 L) | 6 gal. (22 L) | 6 gal. (22 L) |
| LPG Capacity | 2 - 30 lb. | 2 - 30 lb. | 2 - 30 lb. | 2 - 30 lb. |
| Furnace BTU | 35,000 | 35,000 | 35,000 | 35,000 |
| Tire Size | LT235/85R16 | LT235/85R16 | LT235/85R16 | LT235/85R16 |
| Bedroom Height | 76" (1.93 m) | 76" (1.93 m) | 76" (1.93 m) | 76" (1.93 m) |
| Awning Size | 20 ft. (6.10 m) | 18 ft. (5.49 m) | 15 ft. (4.57 m) | 15 ft. (4.57 m) |
