2004 Forest River FLAGSTAFF Specs, Towing Weight, Floorplan + Features
Photo Tour
Available Photos (Click to enlarge)
|
Free Price Quote - No Obligation to Buy
|
| Year: | 2004 |
|---|---|
| Manufacturer: | Forest River |
| Model: | FLAGSTAFF |
| RV Type: | Tent Trailer |
| Condition: | Used |
| Price Range: | $5,000 - $9,000 |
Description
The Flagstaff tent camper is about family values. It's about enjoying good times together at a price families can afford without sacrificing comfort and convenience. Every inch of usable space is transformed into pleasingly functional living quaters. An abundant offering of standard features and available options provides for your family's every need. Best of all, it's built to last through many years of fun and adventure.
Features
CLASSIC STANDARD FEATURES
» Standard Features
- Residential style kitchen faucet w/electric water pump
- Larger deeper sinks
- New soft quilted top innerspring mattresses
- Outdoor gas grill w/ worktable
- Sliding storage tray on all front trunk models
- Water-Pur filtration system w/shower models & hot water pkg.
- E-Z crank-down stabilizer jacks w/sand pads
- Electric brakes (12' models)
- Residential style raised panel doors w/positive latch hardware
- 3 double ceiling lights w/jacks for accessories
- Bunk light w/fan
- Large lift up galley w/backsplash (most models)
- Slide-out range & galley (725D only)
- Permanently mounted 3-burner indoor range w/stove cover
- Free standing table - high pressure laminate
- Comfortable family style dinette w/4" reversible cushions
- Large clothes bar
- LP leak detector
- Drawer Guides
» Seamless, High Density Polyethylene Wells
- Standard Construction Features
- Smooth fiberglass vacuum bonded exterior
- 3-Stage double arm lifter posts
- Fiberglass vacuum bonded radius roof w/No center seam
- Bay window models (524ST,822,823, & 425D)
- 1 Piece screen door on all Classic and MAC models - Except LTD.
- 5 piece sectionalized Vinolon Supreme tenting
- Under floor 20 gallon fresh water tank - Except LTD.
- Powder coated tubular steel frame
- One piece undercoated Structurewood floor
- 13" radial tires (12' models)
- 7-way pigtail plug
- Tent permanently attached on bunk ends and slide-out
- Full perimeter aluminum bed frames
- Tinted vinyl windows
- Powder coated rafter poles and bed bows
- Steel air conditioner vent reinforcing laminated into roof
- Plywood bunk ends
- Independent torsion axles
- Lower door operational in closed position
- 2000 lb. tongue jack w/swivel wheel
MAC STANDARD FEATURES
» Standard Features
- Residential style kitchen faucet w/electric water pump
- Drawer Guides
- Outside gas grill (optional on LTD's)
- Water-Pur filtration system w/all shower models
- Permanently mounted 3-burner indoor range w/range cover (except LTD's)
- Converter w/built-in battery charger
- Electric brakes (12' Models)
- Tinted vinyl windows
- Fold over galley with upper and lower storage
- Exterior work table (Except LTD's)
- LP leak detector
- Automatic safety switch to turn off 12-volt current when roof is closed
- Large built-in ice box
- 1-Piece Screen Door
» Standard Construction Features
- 3 Stage double arm lifter posts
- Fiberglass vacuum bonded radius roof w/ no center seam
- 5-piece Vinolon Supreme tenting
- E-Z crank down stabilizer jacks w/sand pads
- Full perimeter aluminum bed frames
- Plywood bunk ends
- 7-way pigtail wiring
- Under Floor 20 gallon fresh water tank (LTD's feature 10 gallon above floor)
- Powder coated tubular steel frame
- One piece undercoated Structurewood Floor
- Electric brakes (12' models)
- Powder coated rafter poles and bed bows
- Steel air conditioner reinforcing laminated into roof
- 13" radial tires on 12' models (12" radial tires on 8' & 10' models)
- Leaf-spring axle
- Main door operational in closed position
- 2,000 lb. Tongue jack w/swivel wheel
- Seamless, high density polythylene wheel wells
LTD. STANDARD FEATURES
» Standard Features
- Spare tire
- Awning
- Roof vent
- Privacy curtains
- Rear crank down stabilizer jacks w/ sand pads
- Outside recep. (206LTD only)
- Patio light (206LTD only)
- Step
CLASSIC OPTIONS
- Create-A-Breeze 3 speed Fantastic fan
- Thermostatically controlled heated mattresses
- 17,000 BTU forced air furnace w/ electric ignition
- Extra-large 2.5 cubic ft. refrigerator
- A&E free standing awning
- A&E screen room
- Convenience Pkg.- Incl. lined privacy curtains, roof valances, patio light & 110 exteriot outlet
- Hot Water Pkg. - Inclu. Water filter, outside shower, 6 gallon hot water heater & Demand water pump (No outside shower 620 & 720)
- Travel Pkg. - Incl. Spare tire, tire bracket, tire cover, & step
- Overhead kitchen pantry
- Hanging wardrobe
- Power lift system
- Bike rack
- Boat rack
- Battery box and wiring
- Air conditioning wiring kit
- Electric brakes (10' models)
- 13" radial tires (10' models)
- Dual 20 lb. LP bottles
MAC OPTIONS
- Create-A-Breeze 3-Speed Fantastic fan
- Thermostatically controlled heated bed mattresses
- 17,000 BTU forced air furnace w/electric ignition
- Large 1.9 cubic ft. refrigerator
- A & E free standing awning
- Screen room
- Convenience Pkg. - (Incl. Lined privacy curtains, roof valances, patio light & 110 exterior outlet)
- Travel Pkg. - (incl. Spare tire, tire bracket, tire cover, step)
- Shower/Cassette Option (Model 228 incl. Water filtration system, 6 gallon hot water heater, Demand water pump, and Cassette toilet)
- Overhead kitchen pantry
- Power lift system
- Bike rack
- Boat rack
- Battery box and wiring
- Air conditioner wiring kit
- Electric brakes (Standard on 12' models)
- Dual 20 lb. LP bottles
LTD. OPTIONS
- Thermostatically controlled heated bed mattresses
- Large 1.9 cubic ft. refrigerator
- 17,000 BTU forced air furnace w/electronic ignition
- Screen room
- Electric brakes
- Outside gas grill
| Model | 425D | 523 | 524ST | 620 | 625D | 720 | 725D | 822 | 823 | 823D | 825D |
| GVWR (Gross Vehicl... | 3,071 lbs. | 3,036 lbs. | 3,077 lbs. | 2,343 lbs. | 3,072 lbs. | 2,355 lbs. | 3,095 lbs. | 3,011 lbs. | 3,006 lbs. | 3,006 lbs. | 3,070 lbs. |
| Base/Dry Unit Weig... | 2,605 lbs. | 2,297 lbs. | 2,258 lbs. | 1,814 lbs. | 2,539 lbs. | 1,730 lbs. | 2,581 lbs. | 2,283 lbs. | 2,225 lbs. | 2,317 lbs. | 2,447 lbs. |
| Base/Dry Hitch Wei... | 351 lbs. | 316 lbs. | 357 lbs. | 243 lbs. | 352 lbs. | 255 lbs. | 375 lbs. | 291 lbs. | 286 lbs. | 281 lbs. | 350 lbs. |
| Base/Dry Axle Weig... | 2,254 lbs. | 1,981 lbs. | 1,901 lbs. | 1,571 lbs. | 2,187 lbs. | 1,475 lbs. | 2,206 lbs. | 1,992 lbs. | 1,939 lbs. | 2,036 lbs. | 2,097 lbs. |
| Cargo Capacity | 466 lbs. | 739 lbs. | 819 lbs. | 529 lbs. | 533 lbs. | 625 lbs. | 514 lbs. | 728 lbs. | 781 lbs. | 684 lbs. | 623 lbs. |
| Box Size | 12' | 12' | 12' | 10' | 12' | 10' | 12' | 12' | 12' | 12' | 12' |
| Trailer Size (Clos... | 17' 11" | 17' 11" | 17' 11" | 15' 5" | 17' 11" | 14' | 17' 11" | 17' 11" | 17' 11" | 15' 5" | 17' 11" |
| Height (Closed) | 61" | 61" | 61" | 57" | 61" | 57" | 61" | 61" | 61" | 61" | 61" |
| Trailer Lenght (Op... | 23' 6" | 23' 6" | 23' 6" | 20' 2" | 23' 6" | 20' 2" | 23' 6" | 23' 6" | 23' 6" | 23' 6" | 23' 6" |
| Interior Height (O... | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6' | 6' 6" | 6' 6" | 6' 6" | 6' 6" |
| Travel Width | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" |
| Tire Size | 13" R | 13" R | 13" R | 12" R | 13" R | 12" R | 13" R | 13" R | 13" R | 13" R | 13" R |
| Power Converter wi... | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS | 25 AMPS |
| Model | 176ED | 176LTD | 176ST | 205 | 206LTD | 206ST | 208 | 227 | 228 | 228D | 229 |
| GVWR (Gross Vehicl... | 2,259 lbs. | 2,278 lbs. | 2,287 lbs. | 2,355 lbs. | 2,339 lbs. | 2,341 lbs. | 2,319 lbs. | 2,984 lbs. | 2,975 lbs. | 3,015 lbs. | 3,111 lbs. |
| Base/Dry Unit Weig... | 1,336 lbs. | 1,353 lbs. | 1,574 lbs. | 1,635 lbs. | 1,486 lbs. | 1,719 lbs. | 1,569 lbs. | 1,809 lbs. | 1,845 lbs. | 2,079 lbs. | 2,019 lbs. |
| Base/Dry Hitch Wei... | 159 lbs. | 178 lbs. | 187 lbs. | 255 lbs. | 239 lbs. | 241 lbs. | 219 lbs. | 269 lbs. | 255 lbs. | 295 lbs. | 391 lbs. |
| Base/Dry Axle Weig... | 1,177 lbs. | 1,175 lbs. | 1,387 lbs. | 1,380 lbs. | 1,247 lbs. | 1,478 lbs. | 1,350 lbs. | 1,540 lbs. | 1,590 lbs. | 1,784 lbs. | 1,628 lbs. |
| Cargo Capacity | 923 lbs. | 925 lbs. | 713 lbs. | 745 lbs. | 853 lbs. | 622 lbs. | 750 lbs. | 560 lbs. | 510 lbs. | 936 lbs. | 1,092 lbs. |
| Box Size | 8' | 8' | 8' | 10' | 10' | 10' | 10' | 12' | 12' | 12' | 12' |
| Trailer Size (Clos... | 12' | 12' | 14' | 14' | 14' | 15' 11" | 14' | 15' 11" | 15' 11" | 15' 11" | 16' 6" |
| Height (Closed) | 57" | 57" | 57" | 57" | 57" | 57" | 57" | 57" | 57" | 57" | 57" |
| Trailer Lenght (Op... | 17' | 17' | 17' | 20' 2" | 20' 2" | 20' 2" | 20' 2" | 22' 6" | 22' 6" | 22' 6" | 22' 6" |
| Interior Height (O... | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" | 6' 6" |
| Travel Width | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" | 85" |
| Tire Size | 12" R | 12" R | 12" R | 12" R | 12" R | 12" R | 12" R | 13" R | 13" R | 13" R | 13" R |
| Power Converter wi... | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 12 AMPS | 25 AMPS | 12 AMPS |
