2007 Fleetwood RedLine Specs, Towing Weight, Floorplan + Features
Photo Tour
Available Photos (Click to enlarge)
|
Free Price Quote - No Obligation to Buy
|
| Year: | 2007 |
|---|---|
| Manufacturer: | Fleetwood |
| Model: | RedLine |
| RV Type: | Travel Trailer |
| Condition: | New |
| Price Range: | $21,000 - $33,000 |
Description
Lots of what other RV makers call optional is standard on RedLine, meaning you get more value for your hard earned dollar! It's all here - the kitchen, bedroom, bathroom and living areas are all fat with features and ready to roll. Fully tatted with retro graphics, RedLine is miles away from those tennis-white boxes out there. As part of the F.U.E.L family, RedLine is built with the same high-quality craftsmanship and materials that we're famous for. The hip decors available in RedLine put you in the mood to party. And, unlike most of us, it's durable enough to still look good the next morning.
Features
INTERIOR
- 6-Gallon Propane Water Heater w/Bypass
- Commercial Grade Vinyl Flooring
- Flush Floor Cargo Tie-Downs
- Full Systems Monitor Panel
- HydroFlame Forced Air, Direct Spark Ignition Furnace
- Large Overhead Cabinets and Cabinet Doors
EXTERIOR
- 7' 2" Ramp Door Rated at 2,500 Capacity w/Integrated Locking Hardware, Protective Stop Bumpers & Non-Skid Surface
- Dual 7 Gallon (30 lb.) Propane Tanks w/ Sight Gauge
- EZ-Lube Axles
- Fresh Water Tank Quick Drain Knife Valve
- Low Pressure Propane Bib w/Quick Release Fitting
- Propane Tank Cover (Travel Trailer Models)
- R-11 Fiberglass Insulation (Ceiling)
- R-7 Fiberglass Insulation, (Floor, Sidewall, Front Section)
OPTIONS
- 15,000 BTU Air Conditioner
- 6 Gallon LP/Direct Spark Ignition Water Heater
- Divider Wall (Select Models)
- Electric 12V Loft Bunk(s) w/Sofa
- Fold-Up Dinette Seats
- Rock Steady Heavy-Duty Storage Racks & Ladder
- Rock the Box!™ Audio Entertainment System (720W - 7 Speaker, Satellite & MP3 Ready Stereo System w/Dedicated Power Converter)
- Fiberglass Siding (Travel Trailer Models)
- Front Fiberglass Cap (Fifth Wheels Only)
- Generator (Onan®) w/Pump Station (30 or 18 Gal. Tank)
- Generator Ready w/Pump Station (30 or 18 Gallon Tank)
- Heated Holding Tanks
- RVQ Exterior BBQ
| 180FKE | 230FSE | 260FBE | 260FSE | 300FSE | |
| GVWR (lbs) | 8,100 | 9,995 | 10,600 | 10,800 | 12,600 |
| Cargo Carrying Capacity ... | 4,192 | 4,490 | 4,700 | 4,757 | 5,000 |
| Gross Dry Weight (lbs) | 3,908 | 5,505 | 5,900 | 6,043 | 7,600 |
| Hitch Dry Weight (lbs) | 706 | 806 | 1,100 | 1,000 | 1,100 |
| Length (Feet and Inches) | 21' 11" | 27' 3" | 29' 8" | 29' 8" | 35' 2" |
| Height (Feet and Inches) | 12' 2" | 12' 2" | 12' 2" | 12' 2" | 12' 2" |
| Fresh Water Holding Tank... | 50 | 100 | 100 | 100 | 120 |
| Grey Water Holding Tank ... | 40 | 40 | 40 | 40 | 55 |
| Black Water Holding Tank... | 40 | 40 | 40 | 40 | 40 |
| Propane Capacity (lbs.) | 60 | 60 | 60 | 60 | 60 |
| Tire Size | ST225/75R15C | ST225/75R15D | ST225/75R15D | ST225/75R15D | ST225/75R15D |
